ZS4141 – Euro4
Spesifikasi
-
-
Kecepatan Maksimum Km/h 99 Daya Tanjak tan % 70 -
Model – E13C-BJ Model Tipe – Mesin Diesel 4 Langkah Segaris; Direct Injection; Variable Nozzle Turbo; Turbo Charger Intercooler, Common Rail Tenaga Maksimum PS / rpm 410 / 1.800 Daya maksimum Kgm / rpm 204 / 1.100 Jumlah silinder – 6 Diameter x Langkah Piston mm 137 x 146 Isi Silinder mm 12,913 -
Tipe – Single Dry Plate with Damper Spring Diameter Cakram mm 430 -
Tipe – ZF 16S2530 Ke-1 – 13,804 / 11,539 Ke-2 – 9,487 / 7,930 Ke-3 – 6,529 / 5,458 Ke-4 – 4,565 / 3,816 Ke-5 – 3,023 / 2,527 Ke-6 – 2,078 / 1,737 Ke-7 – 1,430 / 1,195 Ke-8 – 1,000 / 0,835 Mundur – 12,923 / 10,803
-
Tipe – Intergral Power Steering Recirculating with Hydrolic Booster Minimal Radius Putar m 11.5
-
Depan – Reversed Elliot, “I” section Belakang – Full Floating Type Spiral Bevel Gear with Hub Reduction Perbandingan Gigi Akhir – 5.410 Sistem Penggerak – Rear 6×4
-
Rem Utama – Full Air with Dual Circuit (ABS Without ASR) Rem Pelambat – Engine Retarder Rem Parkir – Wheel Parking, F1 & R1,R2 Axle
-
Ukuran Rim – 24 x 8.50 – 180 Ukuran Ban – 12.00-R24-18PR Jumlah Ban – 10 (+1) -
Depan & Belakang – Parabolic leaf springs with shock absorbers and stabilizer & Semi-elliptical; Multi Leaf Spring with Stabilizer & torque rod
-
Accu V-Ah 12V – 120Ah x 2 -
Jarak Sumbu Roda mm 4.145 + 1.500 Total Panjang mm 8.245 Total Lebar mm 2.545 Total Tinggi mm 3.205 Lebar Jejak Depan mm 2.065 Lebar Jejak Belakang mm 1.870 Julur Depan mm 1.400 Julur Belakang mm 1.200 Kabin Kesumbu Roda Belakang mm 3.735
-
Kapasitas L 330 -
Berat Kosong kg 10.845 Berat Total Kendaraan kg (GVW) 41.000
